The Affordable Fast Assembly T Prefabricated Office is installed on-site, which will not damage the environment and be green. The prefab house not only has practical value but also has ornamental value. The design is novel, exquisite and elegant, energy-saving and environmental protection, good thermal insulation performance, warm in winter and cool in summer, anti-earthquake and typhoon, comfortable and warm living.
Item No :
PTCOrder(MOQ) :
1Payment :
Telegraphic TransferProduct Origin :
ChinaColor :
CustomizedShipping Port :
Guangzhou/Shenzhen/FoshanLead Time :
3-15China Cheap Prices Fast Assembly T Prefabricated House
The Affordable Fast Assembly T Prefabricated is installed on-site, which will not damage the environment and be green. The prefab house not only has practical value but also has ornamental value. most of the structure of it is completed in the factory.
Product Specification
|
Item No. |
Component |
specification |
|
1 |
Wall Panel |
50 Double Color-coated Steel EPS Sandwich Board |
|
2 |
Roof Title |
50 Double Color-coated Steel EPS Sandwich Board |
|
3 |
Partition wall |
50 Double Color-coated Steel EPS Sandwich Board |
|
4 |
Column |
Double C-shaped Steel Size:80*40*1.8mm |
|
5 |
Roof Beam |
C-Shaped Steel Size:80*40*1.8mm & 50*40*1.8mm |
|
6 |
Tie Rod |
φ8 |
|
7 |
Ground Beam |
Double C-shaped Steel Size:80*40*1.6mm |
|
8 |
Round Beam |
Double C-shaped Steel Size:80*40*1.6mm |
|
9 |
Roof Purlin |
Galvanized Angel Steel:1.5mm |
|
10 |
Door |
50mm Double Colored-coated steel EPS Sandwich Door Size:800*2000mm |
|
11 |
Window |
plastic steel window:1740*925mm |
Easy to Install
Applications
Wide range of applications: it can be used as a large number of offices in the fields of construction, railways, highways, water conservancy, petroleum, commerce, tourism and military，Meeting rooms, dormitories, canteens, entertainment rooms, shops, and various Temporary Housing.
